Phốt bơm Trục ngang Grundfos NB, NBG, NK, NKG - MG1, MG12, MG13

Mã sản phẩm : mg1-mg12-mg13

0đ

Số lượng:

Giới thiệu
Bình luận

Grundfos Pump seal - Phốt bơm Grundfos
Wilo Pump seal - Phốt bơm Wilo, Phớt bơm Wilo
Salmson Pump seal - Phốt bơm Salmson, Phớt bơm Salmson
Mono screw pump seal - Phốt bơm trục vít Mono
Netzch screw pump seal - Phốt bơm trục vít Netzch

Phớt làm kín loại MG1, MG12, MG13

Ứng dụng: Dùng cho bơm nước, bơm nước thải, công nghiệp thực phẩm, công nghiệp giấy, hóa chất, dầu, bơm chìm, bơm tuần hoàn, bơm dầu, vv…

Vật liệu chế tạo: Seal face: Carbon graphite antimony impregnated (A), Carbon graphite resin impregnated (B), Silicon carbide (Q1), Tungsten carbide (U3)Seat: Silicon carbide (Q1, Q2), Tungsten carbide (U3), Special cast CrMo steel (S), Aluminium oxide (V)Elastomer: NBR (P), EPDM (E), FKM (V), HNBR (X4)Metal parts: CrNiMo steel (G), Hastelloy® C-4 (M)

Model MG13: MG13/14-Z, MG13/20-Z, MG13/22-Z, MG13/24-Z, MG13/25-Z, MG13/28-Z, MG13/30-Z, MG13/32-Z, MG13/33-Z, MG13/35-Z, MG13/38-Z, MG13/40-Z, MG13/42-Z, MG13/43-Z, MG13/45-Z, MG13/48-Z, MG13/50-Z, MG13/53-Z, MG13/55-Z,MG13/58-Z, MG13/60-Z, MG13/65-Z, MG13/68-Z, MG13/70-Z, MG13/75-Z

Model MG1: MG1/20-Z, MG1/22-Z, MG1/24-Z, MG1/25-Z, MG1/28-Z, MG1/30-Z, MG1/32-Z, MG1/33-Z, MG1/35-Z, MG1/38-Z, MG1/40-Z, MG1/42-Z, MG1/43-Z, MG1/45-Z, MG1/48-Z, MG1/50-Z, MG1/53-Z, MG1/55-Z,MG1/58-Z, MG1/60-Z, MG1/65-Z, MG1/68-Z, MG1/70-Z, MG1/75-Z

Series MG12: MG12/12-Z, MG12/14-Z, MG12/16-Z, MG12/18-Z, MG12/20-Z, MG12/22-Z, MG12/24-Z, MG12/25-Z, MG12/28-Z, MG12/30-Z, MG12/32-Z, MG12/33-Z, MG12/35-Z, MG12/38-Z, MG12/40-Z, MG12/42-Z, MG12/43-Z, MG12/45-Z, MG12/48-Z, MG12/50-Z, MG12/53-Z, MG12/55-Z, MG12/58-Z, MG12/60-Z, MG12/65-Z, MG12/68-Z, MG12/70-Z, MG12/75-Z

Mechanical seals for all range of Grundfos pumps
Mechanical seals for AMD, AMG, AFG, AP, APG.CDM, CLM, LM, LP, NM, NP,CH, CHI, CHIE,CHIU, CHK, CHV,CLM-CDM-CLP-SKC. CM, CP, CP, CPV, CV, CR, DME,DW, Hilge, JP, KP,LM,LP,NM, NP DNM, DNP, M-MD,MPI,MQ, MS ,MMS, MTA, MTH, MTR, MTC
NB series , NK, S Range, S, SE1, SEV, SEG, SEN, SEG, SP, SPK, SQ, SQE, SQE-NE,TP.TP, TPE, TPD, TPED,UMT, UMTD, UPT, UPTD,UPE, UPED MAGNA, MAGNA,WL WPU,SL, SL1, SLV (HQQE、HQQV、CVBE、CVBV、AQQV、AQQE、KUBV、HUUE、BAQE、GQQE、AUUE、RUUE、BUBE）
CR1s CR1 CR2 CR3 CR4 CR5 CR8 CR10 CR15 CR16 CR20 CR32 CR45 CR64 CR90 HQQE HQQV
CRN1s CRN1 CRN2 CRN3 CRN4 CRN5 CRN8 CRN10 CRN15 CRN16 CRN20 CRN32 CRN45 CRN64 CRN90 (HQQE HQQV)
TP25 TP32 TP40 TP50 TP65 TP80 TP100 TP125 TP150 TP200 BAQE BUBE BQQE GQQE LP
NB NBG BUUE BUUV
CH2 CH4 CH8 CH12 CVBE CVBV
CHI2 CHI4 CHI8 CHI12 BQQV BUBE BQQE
S range pumps, SE and SV series pumps, Grundfos Sarlin pumps , Grundfos Hilge pumps
Part P/N of shaft seas
405096,405347,05347TC,425763,425672,96455082,96455086,96455083,96455087,96455085,96511836,96511840,96511837,96511845,96416584,96433365,96525459,96525490,96436728.
